2020时代的Rails系统测试

1
2
3
4
5
group :test do
  gem 'capybara'
  gem 'selenium-webdriver'
  gem 'cuprite'
end

1
2
3
4
5
# Load general RSpec Rails configuration
require "rails_helper.rb"

# Load configuration files and helpers
Dir[File.join(__dir__, "system/support/**/*.rb")].sort.each { |file| require file }

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
# spec/system/support/capybara_setup.rb

# Usually, especially when using Selenium, developers tend to increase the max wait time.
# With Cuprite, there is no need for that.
# We use a Capybara default value here explicitly.
Capybara.default_max_wait_time = 2

# Normalize whitespaces when using `has_text?` and similar matchers,
# i.e., ignore newlines, trailing spaces, etc.
# That makes tests less dependent on slightly UI changes.
Capybara.default_normalize_ws = true

# Where to store system tests artifacts (e.g. screenshots, downloaded files, etc.).
# It could be useful to be able to configure this path from the outside (e.g., on CI).
Capybara.save_path = ENV.fetch("CAPYBARA_ARTIFACTS", "./tmp/capybara")

1
2
3
4
5
6
7
8
9
10
11
12
# spec/system/support/capybara_setup.rb

Capybara.singleton_class.prepend(Module.new do
  attr_accessor :last_used_session

  def using_session(name, &block)
    self.last_used_session = name
    super
  ensure
    self.last_used_session = nil
  end
end)

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
# spec/system/support/cuprite_setup.rb

# First, load Cuprite Capybara integration
require "capybara/cuprite"

# Then, we need to register our driver to be able to use it later
# with #driven_by method.
Capybara.register_driver(:cuprite) do |app|
  Capybara::Cuprite::Driver.new(
    app,
    **{
      window_size: [1200, 800],
      # See additional options for Dockerized environment in the respective section of this article
      browser_options: {},
      # Increase Chrome startup wait time (required for stable CI builds)
      process_timeout: 10,
      # Enable debugging capabilities
      inspector: true,
      # Allow running Chrome in a headful mode by setting HEADLESS env
      # var to a falsey value
      headless: !ENV["HEADLESS"].in?(%w[n 0 no false])
    }
  )
end

# Configure Capybara to use :cuprite driver by default
Capybara.default_driver = Capybara.javascript_driver = :cuprite

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
module CupriteHelpers
  # Drop #pause anywhere in a test to stop the execution.
  # Useful when you want to checkout the contents of a web page in the middle of a test
  # running in a headful mode.
  def pause
    page.driver.pause
  end

  # Drop #debug anywhere in a test to open a Chrome inspector and pause the execution
  def debug(*args)
    page.driver.debug(*args)
  end
end

RSpec.configure do |config|
  config.include CupriteHelpers, type: :system
end

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
# spec/system/support/better_rails_system_tests.rb

module BetterRailsSystemTests
  # Use our `Capybara.save_path` to store screenshots with other capybara artifacts
  # (Rails screenshots path is not configurable https://github.com/rails/rails/blob/49baf092439fc74fc3377b12e3334c3dd9d0752f/actionpack/lib/action_dispatch/system_testing/test_helpers/screenshot_helper.rb#L79)
  def absolute_image_path
    Rails.root.join("#{Capybara.save_path}/screenshots/#{image_name}.png")
  end

  # Make failure screenshots compatible with multi-session setup.
  # That's where we use Capybara.last_used_session introduced before.
  def take_screenshot
    return super unless Capybara.last_used_session

    Capybara.using_session(Capybara.last_used_session) { super }
  end
end

RSpec.configure do |config|
  config.include BetterRailsSystemTests, type: :system

  # Make urls in mailers contain the correct server host.
  # It's required for testing links in emails (e.g., via capybara-email).
  config.around(:each, type: :system) do |ex|
    was_host = Rails.application.default_url_options[:host]
    Rails.application.default_url_options[:host] = Capybara.server_host
    ex.run
    Rails.application.default_url_options[:host] = was_host
  end

  # Make sure this hook runs before others
  config.prepend_before(:each, type: :system) do
    # Use JS driver always
    driven_by Capybara.javascript_driver
  end
end

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
RSpec.configure do |config|
  # Skip assets precompilcation if we exclude system specs.
  # For example, you can run all non-system tests via the following command:
  #
  #    rspec --tag ~type:system
  #
  # In this case, we don't need to precompile assets.
  next if config.filter.opposite.rules[:type] == "system" || config.exclude_pattern.match?(%r{spec/system})

  config.before(:suite) do
    # We can use webpack-dev-server for tests, too!
    # Useful if you working on a frontend code fixes and want to verify them via system tests.
    if Webpacker.dev_server.running?
      $stdout.puts "\n⚙️  Webpack dev server is running! Skip assets compilation.\n"
      next
    else
      $stdout.puts "\n🐢  Precompiling assets.\n"

      # The code to run webpacker:compile Rake task
      # ...
    end
  end
end

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
# cuprite_setup.rb

# Parse URL
# NOTE: REMOTE_CHROME_HOST should be added to Webmock/VCR allowlist if you use any of those.
REMOTE_CHROME_URL = ENV["CHROME_URL"]
REMOTE_CHROME_HOST, REMOTE_CHROME_PORT =
  if REMOTE_CHROME_URL
    URI.parse(REMOTE_CHROME_URL).yield_self do |uri|
      [uri.host, uri.port]
    end
  end

# Check whether the remote chrome is running.
remote_chrome =
  begin
    if REMOTE_CHROME_URL.nil?
      false
    else
      Socket.tcp(REMOTE_CHROME_HOST, REMOTE_CHROME_PORT, connect_timeout: 1).close
      true
    end
  rescue Errno::ECONNREFUSED, Errno::EHOSTUNREACH, SocketError
    false
  end

remote_options = remote_chrome ? { url: REMOTE_CHROME_URL } : {}

1
2
3
4
5
6
7
8
9
10
11
12
# spec/system/support/cuprite_setup.rb

Capybara.register_driver(:cuprite) do |app|
  Capybara::Cuprite::Driver.new(
    app,
    **{
      window_size: [1200, 800],
      browser_options: remote_chrome ? { "no-sandbox" => nil } : {},
      inspector: true
    }.merge(remote_options)
  )
end

1
2
3
4
5
6
7
8
9
10
module CupriteHelpers
  # ...

  def debug(binding = nil)
    $stdout.puts "🔎 Open Chrome inspector at http://localhost:3333"
    return binding.pry if binding

    page.driver.pause
  end
end

1
2
3
4
5
6
7
8
9
10
# spec/system/support/capybara_setup.rb

# Make server accessible from the outside world
Capybara.server_host = "0.0.0.0"
# Use a hostname that could be resolved in the internal Docker network
# NOTE: Rails overrides Capybara.app_host in Rails <6.1, so we have
# to store it differently
CAPYBARA_APP_HOST = `hostname`.strip&.downcase || "0.0.0.0"
# In Rails 6.1+ the following line should be enough
# Capybara.app_host = "http://#{`hostname`.strip&.downcase || "0.0.0.0"}"

1
2
3
4
5
6
7
8
9
10
# spec/system/support/better_rails_system_tests.rb

module BetterRailsSystemTests
  # ...

  # Use relative path in screenshot message
  def image_path
    absolute_image_path.relative_path_from(Rails.root).to_s
  end
end

1
2
3
4
5
6
7
8
9
# spec/system/support/better_rails_system_tests.rb

config.prepend_before(:each, type: :system) do
  # Rails sets host to `127.0.0.1` for every test by default.
  # That won't work with a remote browser.
  host! CAPYBARA_APP_HOST
  # Use JS driver always
  driven_by Capybara.javascript_driver
end
